XSU cross roller bearing

Type	Basic dimensions(mm)				Mounting hole (mm)			Basic rated loading				Weight	equivalent
	Basic dimensions(mm)				Mounting hole (mm)			Axial		Radial		Weight	equivalent
	Da	di	Di	da	La	Li	nB1	Ca	Coa	Cr	Cor	kg	INA
XSU168	205	130	174	159	190	145	12	65	243	41.4	119	3.3	XSU080168
XSU188	225	150	194	179	210	165	16	70	270	44.5	133	3.7	XSU080188
XSU218	255	180	224	208	240	195	20	76	315	48	154	4.3	XSU080218
XSU258	295	220	264	249	280	235	24	83	370	53	182	5.1	XSU080258
XSU318	355	280	324	309	340	295	28	94	465	60	228	6.3	XSU080318
XSU398	435	360	404	389	420	375	36	106	580	67	185	7.8	XSU080398

Note 1: with the preload nominal modes are XSU***VSP.
